The MAC Viper Profile is a new breed of high-output profile luminaire with an exceptional feature set, superior light quality and a highly efficient optical system. It outperforms all market-leading profiles in the 1200-watt range and is even an alternative to 1500-watt fixtures. The Viper Profile is not only brighter, it is also a faster and more compact solution. With its 1000-watt HID source, the Viper consumes less power, making it over 50% more efficient than its 1200-watt rivals.
26000 lumens – Excellent light quality with a very flat and uniform field
1:5 zoom – Fast zoom with auto-linked focus
Fat beam front lens – The 140 mm front lens exceeds the size of any other fixture in this segment for just the right fat beam look
2 x 5-slot rotating gobo wheels – All glass gobos with optimal focal separation for superior morphing effects
FX wheel – Patent-pending FX wheel provides an additional 4 fixed gobos and 135° animation effect
CMY – Vibrant color mixing with a superior palette of colors including true reds, rich ambers, primary green and deep blues
8-slot color wheel – Fixed colors for added color choice
Linear CTO – Daylight to tungsten CCT control and expansion of the CMY palette
Dimmer and shutter – Combined dimmer/shutter system with intensity effects, instant blackout/open and smooth fades
Iris – Fast and tight iris with adjustable dynamic effects
Strobe – Diverse strobe effects using mechanical or electronic control or in combination
Soft frost – A light frost leaves gobo artwork visible with a beautiful soft edge. Includes a linear focus blurring option
4-facet prism – Real beam separation with rotation and index control for dynamic effects and accurate tiling
Physical
Length (Head): 566 mm (22.3 in.)
Width: 472 mm (18.6 in.)
Width (Base): 335 mm (13.2 in.)
Height (head straight up): 731 mm (28.8 in.)
Height (maximum): 748 mm (29.4 in.)
Weight: 37.2 kg (82.0 lbs.)
Lamp
Approved lamp: Osram HTI 1000/PS Lok-it
Type: 1000 W short-arc discharge
Color temperature: 6000 K
CRI (Color rendering index): >85
Average lifetime: 750 hours
Socket: PGJX36
Ballast: Electronic
Dynamic Effects
Color mixing: CMY, independently variable 0 – 100%
Color temperature control: CTO, variable 6000 – 3200 K
Color wheel: 8 interchangeable dichroic filters + open, indexing, continuous rotation, random color
Aerial wheel: 5 interchangeable aerial effects + open, indexing, continuous rotation and shake
Breakup wheel: 5 interchangeable texture/breakup gobos + open, indexing, continuous rotation and shake
FX wheel: Interchangeable static gobo and gobo animation effects
Prism: Interchangeable 4-facet rotating prism
Iris: 0 – 100%, pulse effects
Frost: Frost filter
Mechanical dimmer/shutter: 0 – 100% continuous dimming, variable & random strobe & pulse effects, instant open & blackout
Dimming options: Choice of four dimming curves
Focus: Range varies with zoom angle, from 2 m (6.6 ft.) / 6 m (19.7 ft.) to infinity (approx.)
Zoom: 10° – 44°
Zoom-focus linking system: 3-zone
Pan: 540°
Tilt: 268°
Position correction system: Absolute position monitoring
Control and Programming
DMX channels: 26/34
Setting and addressing: Control panel with backlit graphic display and jog wheel or via DMX
16-bit control: Aerial, breakup and texture effect rotation and indexing, focus, zoom, pan and tilt
DMX compliance: USITT DMX512-A
RDM compliance: ANSI/ESTA E1.20
Receiver: Opto-isolated RS-485
Firmware update: USB memory device or USB/DMX hardware interface over DMX link
Service Utilities
Fixture identification: User-settable fixture ID number
Construction
Color(s): Black
Housing: UV-resistant fiber-reinforced composite
Reflector: Glass, cold light
Protection rating: IP20
Gobos
Size: E27 (Size E, max. image diameter 27 mm)
Approved material: Borosilicate 3.3 or better with dichroic or heavy matted aluminum coating (metal gobos not approved)
Outside diameter: 37.5 mm (1.5 in.) +0/- 0.2 mm (0.01 in.)
Maximum image diameter: 27 mm (1.1 in.)
Maximum thickness: 1.1 mm (0.04 in.) +/- 0.1 mm (0.004 in.)
Installation
Mounting points: Eight quarter-turn locking points
Orientation: Any
Minimum distance to illuminated surfaces: 3.4 m (11.2 ft.)
Minimum distance to combustible materials: 0.3 m (1.0 ft.)
Connections
AC power input: Neutrik PowerCon
DMX and RDM data in/out: 5-pin locking XLR
USB memory devices: USB host socket
Electrical
AC power: 120-240 V nominal, 50/60 Hz
Power supply unit: Auto-ranging electronic switch-mode
Typical half-cycle RMS inrush current: 16.2 A
Typical Power and Current
120 V, 60 Hz: 1225 W, 10.3 A, PF 0.999
208 V, 60 Hz: 1190 W, 5.8 A, PF 0.996
230 V, 50 Hz: 1186 W, 5.2 A, PF 0.994
240 V, 50 Hz: 1194 W, 5.0 A, PF 0.993
Measurements made at nominal voltage. Allow for a deviation of +/- 10%.
PF = power factor
Thermal
Cooling: Filtered forced air (temperature-regulated, low noise)
Maximum ambient temperature (Ta max.): 40° C (104° F)
Minimum ambient temperature (Ta min.): 5° C (41° F)
Maximum surface temperature, steady state, Ta=40° C: 150° C (302° F)
Total heat dissipation (calculated, +/- 10% at 120 V, 60 Hz): 4180 BTU/hr
